Bandsaw clampıng vice air adjustment
PLC controlled - ornic regulators - automatic adjustment
Up-setting pressure air adjustment
PLC controlled - ornic regulators - automatic adjustment
Pressure Indication
On PLC screen digital
Pressure advice
Limit contrrolled by PLC and direct value taken from list
Jaw distance adjustment
PLC controlled - servo motor control - direct value taken from list
Motion Control
PLC Controlled - Servo Motor Control
Gearbox
Coolless planetary servo gearbox
Annealing Control
More sensitive automatic control by PLC
Program Set
With barcode reader one click - all parameters become setted on the machine in 2 Seconds max.
Basic size change operation and timing
Program selection - 0 Sec
Size selection - 0 Sec
Clamping pressure adjustment - 0 Sec
Up-set pressure adjustment - 0 Sec
Jaw distance adjustment - 2 Sec - maximum distance change
Annealing parallelics control - 20 Sec
Test welding and annealing for new size - no need
Grand total: aprox. 22 Second
Welding capacity by size
6mm - 41mm
Welding capacity by quantity per 8 hours work
400+ Pcs
Cooling Type
Jaws block + Transformer
Receipt Capacity
400 Logs
Clamping Pressure
50 - 300 Bar
Upsetting Pressure
0 - 200 Bar
